Robot Palletizer For Cartons/Bags/Buckets/Packs

Short Description:

The robot palletizing machine, in conjunction with the gripper, picks up the products from the conveyor belt or sorting platform and places them on the pallet. It is extremely flexible and highly integrated. A high-efficiency automatic robotic palletizer can be employed in a variety of production lines, offering production sites intelligent mechanization. It is a palletizing logistic system that can be applied to the beverage, food, soft drink, milk, beer, and water industries, among others. It is frequently used to stack cans, shrink-wrapped goods, bottles, bags, barrels, plastic crates, and cartons. The picking gripper was modified based on the features of the product and is adaptable for a variety of uses.

Model: Li-RP20/25/45/60/80/100

Speed: 20-100 cartons/minute

Send email to us

Product Detail

Product Tags

The robot palletizer conbines Europe technology with China manufacturing advantages, and provide high-end equipment and turnkey projects for primary packaging, secondary packaging, palletizing and depalletizing and also logistics.

Types of Palletizing & De-Palletizing

Bag Palletizing
Case Palletizing
Carton Palletizing
Box Palletizing
Frozen Food Palletizing

De-Palletizing Systems
Pouch Palletizing
Pail Palletizing
Keg Palletizing

Robot Palletizing Systems

We design standard and customized palletizing systems that can increase productivity and save you money. Modular design offers flexibility, high output, and simple operation. Our robot palletizing systems are flexible and can handle virtually any product, including heavy cases, bags, newspapers, cartons, bundles, pallets, pails, totes or trayed products.

SPECIFICATIONS FOR AUTOMATIC ROBOT PALLETIZER
Robot arm	Japanese brand robot	Fanuc	Kawasaki
	German brand robot	KUKA
	Switzerland brand robot	ABB
Main performance parameters	Speed capacity	4-8s per cycle	Adjust according to products and arrangement per layer
	Weight	About 4000-8000kg	Depend on different design
	Applicable product	Cartons, cases, bags, pouch bags, crates	Containers, bottles, cans, buckets, bags etc
Power and air requirements	Compressed air	7bar
	Electric power	17-25 Kw
	Voltage	380v	3 phases

Main configuration

PLC	Siemens(Germany)
Frequency converter	Danfoss (Demark)
Photoelectric sensor	SICK (Germany)
Servo motor	INOVANCE/Panasonic
Servo driver	INOVANCE/Panasonic
Pneumatic components	FESTO (Germany)
Low-voltage apparatus	Schneider(FRANCE)
Touch screen	Siemens (Germany)

Main Features

1) Simple structure, easy in installation and maintains.
2) Adopting advanced world famous brand components in pneumatic parts, electric parts and operation parts.
3) When there is some change about the production line, just need to modify the software program.
4) Running in a high automatization and intellectualization,no pollution
5) Robert Palletizer takes less space and more flexiable , accurate compared to the traditional palletizer.
6) Reducing a lot of labour and labour cost, more productive.
