Servo coordinate carton packing machine
Product details
This machine can achieve automatic feeding, sorting, grabbing, and packing functions;
During production, the products are transported by conveyor belts and automatically arranged according to the arranging requirements. After the products arrangement is finished, a layer of products is clamped by the gripper and lifted to the packing position for packaging. After completing one box, they are recycled to improve production efficiency;
SCAR robots can be equipped to place cardboard partitions in the middle of the products;
Application
This device is used for packing products such as bottles, barrels, cans, boxes, and doypacks into cartons. It can be applied to production lines in industries of beverages, food, pharmaceuticals, and daily chemicals.
Product Display
3D Drawing
- Servo coordinate carton packing line(with cardboard partition)
This production line realizes automatic product infeed conveying, automatic cardboard partition inserting, automatic product grouping, and automatic carton packing to improve the working environment, improve production efficiency, and meet the requirements of customers on production processes and packaging.
Electrical Configuration
| PLC | Siemens |
| VFD | Danfoss |
| Servo motor | Elau-Siemens |
| Photoelectric sensor | SICK |
| Pneumatic components | SMC |
| Touch screen | Siemens |
| Low voltage apparatus | Schneider |
| Terminal | Phoenix |
| Motor | SEW |
Technical Parameter
| Model | LI-Li-CRP12/20/30/50 |
| Speed | 15-50cartons/min |
| Power supply |
3 x 380 AC ±10%，50HZ，3PH+N+PE. |
